Hydraulic Hose SAE 100 R9
Hydraulic Hose SAE 100 R9
Hydraulic Hose SAE 100 R9 is a high pressure hose which can bear max 28 Mpa. It can bear such high pressure because it has a special reinforce which is 4 layers of steel wire braid. The NBR material offers excellent oil resistance.
Hydraulic Hose SAE 100 R9 Details
Inner tube: Black, oil resident nitrile rubber
Cover: Black and oil resistant nitrile rubber
Reinforcement: 4 alternating layers of spiral and high tensile steel wire.
Application: Hydraulic system service with petroleum and water based fluids, for general industrial use
Temperature range: -40℉ to +250℉ (-40℃ to +121℃)
Size: 3/8″ to 2″
Hydraulic Hose SAE 100 R9
SAE 100 R9/R10/R12 Steel Wire Spiraled Hydraulic Hose is suitable for delivering petroleum based hydraulic oils mainly used in high pressure working conditions. R9 hydraulic hose is composed of three parts: tube, reinforcement and cover. The tube is made from black and oil resistant synthetic rubber, making it have outstanding performance in delivering petroleum based hydraulic oils. The reinforcement is made from four layers of high tensile and high strength thick spiraled steel wires in alternating direction, making the hose resistant to extremely high pressure. While the cover is made from high quality synthetic rubber, which is resistant to abrasion, corrosion, weather, ozone, cut, aging and sunlight. Inquiry now!
SAE 100 R9/R10/R12 Steel Wire Spiraled Hydraulic Hose is ideal for extremely high pressure and high impulse hydraulic applications. 100 R9 exceeds all the performance requirements OF SAE 100 R9 / R10 / R12, EN856 R9 / R10 / R12, SAE 100 R12 and EN856 4SP. Compatible with biodegradable hydraulic fluids like synthetic esters, polyglycols and vegetable oils as well as petroleum based fluids.
Hydraulic Hose SAE 100 R9
| Metric Size | Inch Size | SAE Dash Size | ID | WD | OD | WP | BP | BR | ||||
| min | max | min | max | min | max | |||||||
| mm | inch | dash | mm | mm | mm | mm | mm | mm | mpa | psi | mpa | mm |
| 10 | 3/8 | 06 | 9.3 | 10.1 | 16.6 | 17.8 | 19.5 | 21.0 | 28.0 | 4060 | 112.0 | 125 |
| 12.5 | 1/2 | 08 | 12.3 | 13.5 | 19.9 | 21.5 | 23.0 | 24.6 | 28.0 | 4060 | 112.0 | 180 |
| 16 | 5/8 | 10 | 15.5 | 16.7 | 23.8 | 25.4 | 26.5 | 28.2 | 28.0 | 4060 | 112.0 | 200 |
| 19 | 3/4 | 12 | 18.6 | 19.8 | 26.9 | 28.4 | 29.9 | 31.5 | 28.0 | 4060 | 112.0 | 240 |
| 25 | 1 | 16 | 25.0 | 26.4 | 34.1 | 35.7 | 36.8 | 39.2 | 28.0 | 4060 | 112.0 | 300 |
| 31.8 | 1-1/4 | 20 | 31.4 | 33.0 | 42.7 | 45.1 | 45.4 | 48.6 | 21.0 | 3050 | 84.0 | 420 |
| 38 | 1-1/2 | 24 | 37.7 | 39.3 | 49.2 | 51.6 | 51.9 | 55.0 | 17.5 | 2540 | 70.0 | 500 |
| 51 | 2 | 32 | 50.8 | 52.0 | 62.5 | 64.8 | 65.1 | 68.3 | 17.5 | 2540 | 70.0 | 640 |
Get A Quotation
Hiteck is your expert in hose solutions. Our high quality product, competitive price and extreme service will offer you the best purchase experience. Contact us now for more details and start our business relationship.
+86 177 3386 3281
Related Products
FAQ
What's the material of such hose?
Both of the inner tube and cover are nitrile rubber. Because it has the excellent oil resistance among the rubbers.
Can the hose work at high pressure?
Yes it can work at high pressure. As it has a 4-layer steel wire reinforce.
What is the size available?
The common sizes are 3/8” to 2”.
