Nylon Fabric Duct Hose
PVC Nylon Fabric Duct Hose
PVC Nylon Fabric Duct Hose is made from PVC coated nylon fabric with spring steel wire. It is very flexible and compressiable. Thus it will be easy to use and recycle. What’s more, it’s very durable so that can serve for a long time.
Details
Spiral: Spring steel wire
Wall: pvc coated polyester fabric
Features: Vibration resistant
Tearing resistant, high tensile strength
Small bending radius, kink-proof
Temperature: -20 to +80℃
Size: ID 2″to 16″
PVC Nylon Fabric Duct Hose
Nylon Fabric Duct Hose is a flexible lightweight duct hose produced from durable coated polyester fabric. This fabric flexible air duct hose can be used in a variety of industrial air movement and blower applications. Each fabric flexible ventilation duct hose has been reinforced with a spring steel wire helix for added strength and flexibility.
Nylon Fabric Duct Hose is designed for volume air movement in indoor or outdoor applications. This Fabric Air Ducting lightweight hose is ideal for general air ventilation, mobile chillers, welding gas extraction, air conditioning and ventilation of fumes, light duty dust extraction, and air movement, and light dust movement applications.
PVC Nylon Fabric Duct Hose Structure:
Wall: pvc coated polyester fabric
Spiral: steel wire helix
Application:
●As nylon fabric duct hose ideal for ventilation of fumes,dust extraction&collection,and air movement.
●Air conditioning and ventilation of fumes,light duty dust extraction,and air movement.
●As a flexible connection between grilles diffusers,fans and other air movement units
●Suction of engine exhaust gas
●Exhaust gas technique, engine construction, engine warming, aircraft construction and military construction
●For flue gas extraction, blast furnace exhaust and engine test bench
Features:
●Vibration resistant
●Tearing resistant
●High tensile strength
●Minimum weight
●Highly flexible and compressible up to 10:1
●Very small bending radius
Working temperature: -20 to +80℃
Inner diameter 2″-16″
Length: 10m/roll
PVC Nylon Fabric Duct Hose Specification
| ID | OD | L | WP | BP | Weight | |||
| inch | mm | mm | m/roll | psi | bar | psi | bar | kg/roll |
| 3/8" | 10.0 | 14.0 | 50 | 116 | 8 | 348 | 24 | 5.09 |
| 1/2" | 11.0 | 15.0 | 15 | 116 | 8 | 348 | 24 | 1.65 |
| 1/2" | 12.0 | 15.4 | 30 | 87 | 6 | 261 | 18 | 2.96 |
| 1/2" | 12.0 | 15.4 | 50 | 87 | 6 | 261 | 18 | 4.94 |
| 1/2" | 12.0 | 15.4 | 100 | 87 | 6 | 261 | 18 | 9.87 |
| 1/2" | 12.0 | 15.6 | 30 | 87 | 6 | 261 | 18 | 3.16 |
| 1/2" | 12.0 | 15.6 | 50 | 87 | 6 | 261 | 18 | 5.26 |
| 1/2" | 12.0 | 15.6 | 100 | 87 | 6 | 261 | 18 | 10.53 |
| 1/2" | 12.0 | 16.0 | 30 | 87 | 6 | 304 | 21 | 3.56 |
| 1/2" | 12.0 | 16.0 | 50 | 87 | 6 | 304 | 21 | 5.93 |
| 1/2" | 12.0 | 16.0 | 100 | 87 | 6 | 304 | 21 | 11.87 |
| 5/8" | 15.0 | 19.0 | 50 | 87 | 6 | 290 | 20 | 7.21 |
| 5/8" | 15.0 | 19.0 | 100 | 87 | 6 | 290 | 20 | 14.41 |
| 5/8" | 15.0 | 20.0 | 25 | 87 | 6 | 290 | 20 | 4.64 |
| 5/8" | 15.0 | 20.0 | 30 | 87 | 6 | 290 | 20 | 5.56 |
| 5/8" | 16.0 | 21.0 | 10 | 72 | 5 | 261 | 18 | 1.96 |
| 5/8" | 16.0 | 21.0 | 30 | 72 | 5 | 261 | 18 | 5.88 |
| 5/8" | 16.0 | 21.0 | 50 | 72 | 5 | 261 | 18 | 9.8 |
| 5/8" | 16.0 | 21.0 | 100 | 72 | 5 | 261 | 18 | 19.61 |
| 3/4" | 19.0 | 22.0 | 20 | 72 | 5 | 215 | 15 | 2.61 |
| 3/4" | 19.0 | 23.0 | 30 | 72 | 5 | 215 | 15 | 5.34 |
| 3/4" | 19.0 | 24.0 | 50 | 72 | 5 | 215 | 15 | 11.39 |
| 1" | 25.0 | 30.0 | 50 | 43 | 3 | 130 | 9 | 14.57 |
Get A Quotation
Hiteck is your expert in hose solutions. Our high quality product, competitive price and extreme service will offer you the best purchase experience. Contact us now for more details and start our business relationship.
