Silicone Hose Coupler
Silicone Hose Coupler
Silicone Hose Coupler meets the Sae J30 standard. It is ideal for heavy duty connection in engine system at high temperature conditions. For example, turbo system. Besides, it’s also ideal for industrial and marine use.
Silicone Hose Coupler Details
Inner: 100% High quality silicone Cover: silicone Reinforcement: 4ply Polyester/Aramid fabric with helix wire
Color: Black/Red/Blue/Green/Yellow
No odor, no toxic, eco-friendly
High temperature and aging resistant
Temperature range: -40℃ (-104℉) to +220℃ (+428 ℉)
Size: ID 25mm to 102mm
Silicone Hose Coupler
Silicone Straight Coupler meet or exceed SAEJ20 standard, ideal for heavy duty pressure connections in hostile engine environments, extreme temperatures and various pressure ranges where high performance levels are required. great for marine and industrial use, custom turbo or intercooler piping fabrication, DIY intake or radiator cooling system.
Constructed from hand-wrapped, 4-ply, high-grade silicone, these couplers feature superior temperature resistance rated for -104 degrees F to 428 degrees F. Vibrant Performance reinforced hose couplers are strong and reliable–they won’t swell or burst under extreme conditions. Vibrant Performance offers these couplers in straight, transition, and hump styles in a variety of sizes and lengths to meet your fabrication needs.
Silicone Hose Coupler Application:
Joining your intake pipe to the throttle body assembly, air metering assembly, intercooler, BOV pipe, or turbo inlet/outlet. Custom compressor, intercooler or inlet piping for turbo/supercharged car. Custom cold air intake for nonturbo car,Custom cold air intake for nonturbo car .These silicone parts can be used in trucks, recreational vehicles, boats, or anything else with an engine
Silicone Hose Coupler Features:
1.Good electrical insulating performance
2.No odor, no toxic, eco-friendly.
3.High temperature and resistant
4.Having physical laziness, good air permeability
5.We offer OEM/ODM, We can 3D design, produce according to your drawings
Silicone Hose Coupler Specification
| ID | Layer | Thickness | Length | ID | Layer | Thickness | Length | ||
| inch | mm | ply | mm | mm | inch | mm | ply | mm | mm |
| 1/4" | 6 | 3-4 | 4-4.5 | 76/102/152 | 1-1/2" | 38 | 4 | 4.5-5 | 76/102/152 |
| 5/16" | 8 | 3-4 | 4-4.5 | 76/102/152 | 1-3/4" | 45 | 4 | 4.5-5 | 76/102/152 |
| 3/8" | 10 | 3-4 | 4-4.5 | 76/102/152 | 2" | 51 | 4 | 4.5-5 | 76/102/152 |
| 1/2" | 12 | 3-4 | 4-4.5 | 76/102/152 | 2-1/4" | 57 | 4 | 4.5-5 | 76/102/152 |
| 5/8" | 16 | 3-4 | 4-4.5 | 76/102/152 | 2-1/2" | 63 | 4 | 4.5-5 | 76/102/152 |
| 3/4" | 19 | 3-4 | 4-4.5 | 76/102/152 | 2-3/4" | 70 | 4 | 4.5-5 | 76/102/152 |
| 1" | 25 | 4 | 4.5-5 | 76/102/152 | 3" | 76 | 4 | 4.5-5 | 76/102/152 |
| 1-1/4" | 32 | 4 | 4.5-5 | 76/102/152 | 3-1/2" | 89 | 4 | 4.5-5 | 76/102/152 |
| 1-3/8" | 35 | 4 | 4.5-5 | 76/102/152 | 4" | 102 | 4 | 4.5-5 | 76/102/152 |
Get A Quotation
Hiteck is your expert in hose solutions. Our high quality product, competitive price and extreme service will offer you the best purchase experience. Contact us now for more details and start our business relationship.
+86 177 3386 3281
Related Products
Silicone Elbow Hose
Reducer Silicone Hose
Silicone T Hose
FAQ
What's the size available?
We can offer you any sizes as your demand. You can just tell us the size you need, then we can customize for you.
What's the color available?
We can offer you any colors like black, yellow, red and others.
What will be the delivery time?
The delivery time will be within 30 days.
