Silicone Hump Hose
Silicone Hump Hose
Silicone Hump Hose absorbs high quality silicone as the raw material. It’s flexible, non toxic and odorless. It’s ideal for heating and cooling system, air intake system and other systems in vehicles.
Details
Inner: 100% High quality silicone Cover: silicone Reinforcement: 4ply Polyester/Aramid fabric with helix wire
Color: Black/Red/Blue/Green/Yellow
No odor, no toxic, eco-friendly
High temperature aging resistant
Temperature range: -40℃ (-104℉) to +220℃ (+428℉)
Size:ID 16mm to 89mm
Silicone Hump Hose
Hump Hose features multi-ply reinforced high temperature material,for which meet or exceed SAEJ20 Standard. Silicone Hump Hose are used by professionals in industries such as high performance racing vehicles, commercial truck and bus, marine, agricultural and off highway vehicles, turbo diesel, food and beverage.
Such silicone hose is built for endurance and performance in custom turbo intake systems, designed to join two intake tubes while adding a flexible joint to isolate engine vibrations. Hand crafted and quality inspected to the highest European standards. Black with a smooth, shiny “wipe-down” finish.
Silicone Hump Hose Application:
Heating and Cooling Systems, CAC Charge-Air-Cooler (Hot & Cold side), Turbo Charger Systems & Custom Compressor, Intercooler or Intake & Inlet Piping for turbo/Superchargers etc.
Silicone Hump Hose Features:
1.Good electrical insulating performance
2.No odor, no toxic, eco-friendly.
3.Having physical laziness, good air permeability
4.We offer OEM/ODM, We can 3D design, produce according to your drawings
Silicone Hump Hose Specification
| ID | Layer | Thickness | Length | ID | Layer | Thickness | Length | ||
| inch | mm | ply | mm | mm | inch | mm | ply | mm | mm |
| 1" | 25.0 | 4 | 4.5-5 | Customized | 2 1/2" | 63.0 | 4 | 4.5-5 | Customized |
| 1 1/4" | 32.0 | 4 | 4.5-5 | 2 3/4" | 70.0 | 4 | 4.5-5 | ||
| 1 1/2" | 38.0 | 4 | 4.5-5 | 3" | 76.0 | 4 | 4.5-5 | ||
| 1 3/4" | 45.0 | 4 | 4.5-5 | 3 1/8" | 80.0 | 4 | 4.5-5 | ||
| 2" | 51.0 | 4 | 4.5-5 | 3 1/4" | 83.0 | 4 | 4.5-5 | ||
| 2 1/8" | 54.0 | 4 | 4.5-5 | 3 1/2" | 89.0 | 4 | 4.5-5 | ||
| 2 1/4" | 57.0 | 4 | 4.5-5 | 3 3/4" | 95.0 | 4 | 4.5-5 | ||
| 2 3/8" | 60.0 | 4 | 4.5-5 | 4" | 102.0 | 4 | 4.5-5 |
Get A Quotation
Hiteck is your expert in hose solutions. Our high quality product, competitive price and extreme service will offer you the best purchase experience. Contact us now for more details and start our business relationship.
+86 177 3386 3281
Related Products
Silicone Straight Hose
Corrugated Silicone Hose
Silicone Steel Wire Hose
FAQ
What is the purpose of a silicone hump hose?
It widely serves in automotive, marine, and industrial applications. They are commonly used in engine intake and exhaust systems, cooling systems, and other areas where flexibility and vibration absorption are required. The hump design allows for movement and expansion in the hose while maintaining a sealed connection.v
How should I install and maintain the hose?
To install a silicone hump hose, ensure that both ends are securely connected to the mating components, using appropriate clamps or couplings. Avoid over-tightening the clamps to prevent damage to the hose. Regularly inspect the hoses for signs of wear, cracking, or degradation, and replace them if necessary. Clean the hoses with mild soap and water, avoiding harsh chemicals that may damage the silicone material.
How many humps are available?
We can offer you the hose with any numbers of hump. You can just tell us the specs you want. Then we can customize for you.
