Silicone Reducer Hose
Silicone Reducer Hose
Silicone Reducer Hose has a 4-ply polyster reinforce. Thus it is strong and durable. With excellent properties, he hose is ideal for professional use. For example, high performance racing car. Besides, it widely serves in various of vehicles such as truck and car.
Silicone Reducer Hose Details
Inner: 100% High quality silicone Cover: silicone Reinforcement: 4ply Polyester/Aramid fabric with helix wire
Color: Black/Red/Blue/Green/Yellow
No odor, no toxic, eco-friendly
High temperature and aging resistant
Temperature range: -40℃ (-104℉) to +220℃ (+428℉)
Size: ID 16mm to 89mm
Reducer Hose features 4-ply reinforced high temperature material, for which meet or exceed SAEJ20 Standard. Silicon Reducing Coupler Hoses are used by professionals in industries such as high performance racing vehicles, commercial truck and bus, Marine, agricultural and off highway vehicles, turbo diesel, food and beverage, and general manufacturing industries.
Silicone Reducer Hose Application:
Heating and Cooling Systems, CAC Charge-Air-Cooler (Hot & Cold side) , Turbo Charger Systems & Custom Compressor, Intercooler or Intake & Inlet Piping for turbo/Superchargers. etc.
Silicone Reducer Hose Features:
1.Good electrical insulating performance.
2.No smell, no toxic, eco-friendly.
3.High temperature and aging resistant
4.Having physical laziness,Good air permeability
5.We offer OEM/ODM and we can 3D design. Besides, we can produce according to your drawings
Silicone Reducer Hose Specification
| ID | Layer | Thickness | Length | ID | Layer | Thickness | Length | ||
| inch | mm | ply | mm | mm | inch | mm | ply | mm | mm |
| 3/4"-5/8" | 19-16 | 3-4 | 4-4.5 | 76, 102, 152, etc | 1 3/4"-1 1/4" | 45-32 | 4 | 4.5-5 | 76, 102, 152, etc |
| 7/8"-3/4" | 22-19 | 3-4 | 4-4.5 | 1 3/4"-1 3/8" | 45-35 | 4 | 4.5-5 | ||
| 1"-5/8" | 25-16 | 4 | 4.5-5 | 1 7/8"-1 1/8" | 48-29 | 4 | 4.5-5 | ||
| 1"-3/4" | 25-19 | 4 | 4.5-5 | 1 7/8"-1 1/2" | 48-38 | 4 | 4.5-5 | ||
| 1"-7/8" | 25-22 | 4 | 4.5-5 | 1 7/8"-1 18/25" | 48-44 | 4 | 4.5-5 | ||
| 1 1/8"-1" | 28-25 | 4 | 4.5-5 | 1 24/25"-1 5/8" | 50-41 | 4 | 4.5-5 | ||
| 1 3/16"-1" | 30-25 | 4 | 4.5-5 | 2"-1" | 51-25 | 4 | 4.5-5 | ||
| 1 3/8"-1 | 35-25 | 4 | 4.5-5 | 2"-1 1/4" | 51-32 | 4 | 4.5-5 | ||
| 1 3/8"-1 1/8" | 35-28 | 4 | 4.5-5 | 2 3/8"-2 4/25" | 60-55 | 4 | 4.5-5 | ||
| 1 1/2"-1" | 38-25 | 4 | 4.5-5 | 3"-2" | 76-51 | 4 | 4.5-5 | ||
| 1 1/2"-1 1/4" | 38-32 | 4 | 4.5-5 | 3" 2 1/2" | 76-63 | 4 | 4.5-5 | ||
| 1 5/8"-1" | 41-25 | 4 | 4.5-5 | 3 1/8"-2 3/4" | 80-70 | 4 | 4.5-5 | ||
| 1 5/8"-1 1/2" | 41-38 | 4 | 4.5-5 | 3 1/2"-2 13/25" | 89-64 | 4 | 4.5-5 | ||
| 1 18/25-1" | 44-25 | 4 | 4.5-5 | 3 9/10"-3 1/4" | 100-83 | 4 | 4.5-5 | ||
| 1 18/25-1 5/8" | 44-41 | 4 | 4.5-5 | 5 9/10"-4" | 150-102 | 4 | 4.5-5 |
Get A Quotation
Hiteck is your expert in hose solutions. Our high quality product, competitive price and extreme service will offer you the best purchase experience. Contact us now for more details and start our business relationship.
+86 177 3386 3281
Related Products
Silicone Elbow Hose
Silicone Heater Hose
Hose Coupler
Silicone T Hose
FAQ
What is a silicone reducer hose?
It is to connect two pipes or components with different diameters. It is called a reducer hose because it reduces the diameter of one end to fit onto a smaller pipe or component.
What's the size of such hose?
It can be different sizes to meets various vehicles and hoses.
Can you produce according to my drawing?
Yes of course. We can customize the special hose as per your drawing.
