Peristaltic Pump Hose
Peristaltic Pump Hose
Peristaltic Pump Hose is specially designed for a peristaltic pump. The hose can be 4 layers of steel wire braid, 4 layers of wire braid and more layers of reinforcement according to your demand. It widely serves in food industry, tunnel, construction and many other places.
Details
Tube: Black and smooth rubber compound
Cover: Black and smooth rubber compound
Reinforcement: Multiply of heavy duty synthetic cord
The peristaltic pump hoses are specifically engineered for peristaltic pumps. It is designed and manufactured for long operational life and minimized cost.
Peristaltic Pump Hose
Peristaltic Pump Hose is fitted in a peristaltic pump – there the rotor with a number of rollers or shoes compress the tubing and forces liquid or semi-liquid substances to move. Peristaltic pump tubing is made from extremely flexible rubber (natural rubber, NBR, CSM, EPDM, silicone and others) and resistant to compression, friction with an adequate level of chemical resistance. They can be textile reinforced.
Structure:
Tube: Black and smooth rubber compound
Reinforcement: Multiply of heavy duty synthetic cord
Cover: Black and wrapped synthetic rubber
Application:
The peristaltic pump hoses are specifically engineered for peristaltic pumps. It is designed and manufactured for long operational life and minimized cost.
Features:
●Extremely durable; High abrasion, ozone & weather resistance.
●The lowest possible friction between the hose and roller
Temperature: -40℃ to +100℃
Peristaltic Pump Hose Specification
| ID | OD | L | WP | BP | Weight | |||
| inch | mm | mm | m/roll | psi | bar | psi | bar | kg/roll |
| 3/8" | 10.0 | 14.0 | 50 | 116 | 8 | 348 | 24 | 5.09 |
| 1/2" | 11.0 | 15.0 | 15 | 116 | 8 | 348 | 24 | 1.65 |
| 1/2" | 12.0 | 15.4 | 30 | 87 | 6 | 261 | 18 | 2.96 |
| 1/2" | 12.0 | 15.4 | 50 | 87 | 6 | 261 | 18 | 4.94 |
| 1/2" | 12.0 | 15.4 | 100 | 87 | 6 | 261 | 18 | 9.87 |
| 1/2" | 12.0 | 15.6 | 30 | 87 | 6 | 261 | 18 | 3.16 |
| 1/2" | 12.0 | 15.6 | 50 | 87 | 6 | 261 | 18 | 5.26 |
| 1/2" | 12.0 | 15.6 | 100 | 87 | 6 | 261 | 18 | 10.53 |
| 1/2" | 12.0 | 16.0 | 30 | 87 | 6 | 304 | 21 | 3.56 |
| 1/2" | 12.0 | 16.0 | 50 | 87 | 6 | 304 | 21 | 5.93 |
| 1/2" | 12.0 | 16.0 | 100 | 87 | 6 | 304 | 21 | 11.87 |
| 5/8" | 15.0 | 19.0 | 50 | 87 | 6 | 290 | 20 | 7.21 |
| 5/8" | 15.0 | 19.0 | 100 | 87 | 6 | 290 | 20 | 14.41 |
| 5/8" | 15.0 | 20.0 | 25 | 87 | 6 | 290 | 20 | 4.64 |
| 5/8" | 15.0 | 20.0 | 30 | 87 | 6 | 290 | 20 | 5.56 |
| 5/8" | 16.0 | 21.0 | 10 | 72 | 5 | 261 | 18 | 1.96 |
| 5/8" | 16.0 | 21.0 | 30 | 72 | 5 | 261 | 18 | 5.88 |
| 5/8" | 16.0 | 21.0 | 50 | 72 | 5 | 261 | 18 | 9.8 |
| 5/8" | 16.0 | 21.0 | 100 | 72 | 5 | 261 | 18 | 19.61 |
| 3/4" | 19.0 | 22.0 | 20 | 72 | 5 | 215 | 15 | 2.61 |
| 3/4" | 19.0 | 23.0 | 30 | 72 | 5 | 215 | 15 | 5.34 |
| 3/4" | 19.0 | 24.0 | 50 | 72 | 5 | 215 | 15 | 11.39 |
| 1" | 25.0 | 30.0 | 50 | 43 | 3 | 130 | 9 | 14.57 |
Get A Quotation
Hiteck is your expert in hose solutions. Our high quality product, competitive price and extreme service will offer you the best purchase experience. Contact us now for more details and start our business relationship.
